CHAPTER 6
6-68
To disassemble the berth reverse the
process. Make sure that the backrest
cushion clip plates are fi rmly pushed
into the backrest holders.
When storing the support bars the
longest bar must be placed in the
most inside slots or it will not fi t.
Push the bars completely down in
the rubber holders.
See the illustrations below.
Longest Bar
TYPICAL CUSHION
CLIP PLATE
BACKREST HOLDER
PORT
BERTH
CUSHION
STBD.
BERTH
CUSHION
TYPICAL BERTH
LONGEST SUPPORT
BA
R
