Regal 2500 - Page 337

2500 FUEL SYSTEM
12-18
04
1-1/8" BILGE FLEX HOSE- 8FT
1
DESCRIPTIONQTY.
1
1-1/2" FUEL FILL HOSE - 8FT
1
1
03
ITEM
02
3/8" FUEL CARB - 3FT
PART #
01
1769
1776
BILL OF MATERIALS
17705/8" FUEL VENT HOSE- 8FT
1463
C. WOO
2500 FUEL SYSTEM
DRAWING TITLE:
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
ALL RIGHTS RESERVED
APP. BY
REGAL MARINE INDUSTRIES
MME23A
SCALE:
DR. BY
DATE:
REVISION DESCRIPTION
REV. DATE
APPROVED BY:DRAWN BY:
DWG. NO.:
10-31-08
WATER
TANK
FUEL TANK
NOTE: DO NOT STRAP HOSES TOGETHER.
2500 FUEL SYSTEM
FUEL VENT
TO ENGINE
FUEL FILL
BILGE THRU HULL
BILGE PUMP
