Regal 2500 - Wire Color Codes

CHAPTER 4
4-2
WIRE COLOR CODES
Color Gauge Function
(solid color/stripe)
Red 00 Battery Cable To Engine
Black 16 to 4 All Grounds
Black/White 16 Halon Fire Extinguisher
Brown 12 Water Pressure Pump
Brown 16 Aft Bilge Pump/Manual
Brown 16 Fwd. Bilge Pump/Manual
Brown/Black 10 Overboard Discharge Pump
Brown/White 16 Aft Auto Bilge Pump
Brown/Red 16 Fwd. Auto Bilge Pump
Brown/Pink 16 CO Detector
Yellow 12 Blower
Yellow/Black 16 Stereo Memory
Orange 12 Refrigerator, Hatch Ram
Orange 16 Windshield Wiper/Run
Orange/White 16 Windshield Wiper/Park
Orange/Black 16 Horn
Orange 10 Spotlight
Blue 14 Interior Lights
Blue/White 14 Cockpit Lights
Yellow/Red 14 Engine Cranking Circuit
Blu/Green 16 Underwater Lights
