33
Systems
ENGINE IGNITION SWITCH
Cummins dual ignition switches are used to crank over
and start the diesel engines. The left ignition switch con-
trols the port engine and the right ignition switch controls
the starboard engine.
Each ignition switch features 3 used positions rotating
left to right starting from the vertical position:
STOP- SPRING LOADED TO THE LEFT.
AUXILIARY- NOT USED
ON- SUPPLIES IGNITION POWER TO ENGINE.
START- SPRING LOADED TO THE RIGHT.
Refer to the Cummins operator’s manual for further in-
formation.
AVOID POSSIBLE BODILY INJURY OR DEATH!
REMOVE KEYS FROM THE IGNITION
SWITCHES WHEN THE ENGINES
ARE NOT RUNNING.
