TYPICAL 12 VOLT MAIN DC PANEL METER/BREAKER SWITCH FUNCTIONS
FWD. STATEROOM LTS- (15 AMP) protects the
overhead and reading lights.
SALON LTS- (15 AMP) protects the main cabin over-
head and counter top lights.
AFT STATEROOM LTS- (15 AMP) protects over-
head and reading lights.
TANK MONITOR- (3 AMP) protects the fresh water
and waste tank monitor located at salon main AC panel.
SATELLITE TV SYSTEM- (15 AMP) protects the
system’s mechanical-electronic components.
TV ANTENNA- (15 AMP) protects the antenna
mounted on the hardtop.
GALLEY/FWD HEAD VENT- (15 AMP) protects
the fan that runs the vent. This fan also serves the for-
ward head.
WATER PUMP-(15 AMP) protects fresh water pres-
sure pump located in the main cabin forward fl oor.
BOOST PUMP- (20 AMP) an additional fresh water
pressure pump to provide more system hose pressure.
MACERATOR- (15 AMP) protects the overboard dis-
charge pump which pumps waste overboard. To activate
fi rst pull the cover up and then turn on the breaker.
FWD. HEAD- (15 AMP) protects forward head circuit.
AFT HEAD-(15 AMP) protects the aft head circuit.
SOFT LIGHTS- (15 AMP) protects the soft lights in
the salon, forward and aft stateroom behind the blind
valence.
AFT HEAD VENT- (15 AMP) protects aft head vent
fan motor.
SALON 12 VOLT OUTLET- (15 AMP) protects ac-
cessory plug.
FORWARD STATEROOM 12 VOLT OUTLET- (15
AMP) protects accessory plug.
AFT BERTH 12 VOLT OUTLET- (15 AMP) pro-
tects accessory plug.
ACC- (5 AMP) provides aftermarket accessory protec-
tion.
ACC- (10 AMP) provides aftermarket accessory protec-
tion.
FORWARD STATEROOM DVD- (10 AMP) protects
the forward cabin DVD player.
STABILIZER- (25 AMP) protects the DC side of the
optional Seakeeper® option functions.
AFT CHARGER (10 AMP)- protects the circuitry that
operates the battery charger for the optional electric din-
gy motor.
ACC- (10, 15 , & 20 AMP) protects each of the 4 acces-
sory breakers. Notice that the sizes of the breakers vary.
This is important when adding additional components.
SEA CHEST- (30 AMP) protects the sea chest pump
circuitry.
CO MONITOR- (3 AMP EACH) protects separately
the 3 CO detectors located in the forward, salon and mas-
ter staterooms. To access these breakers fi rst pull the cov-
er up from right to left. At this point the breaker can be
turned off. For protection purposes these breakers shall
be left in the “on” position.
