If the motor does not shut off at the end of the
cycle, check the delay times and wait for the
delays to time out. Also make sure that there is no
call for “Continuous fan” on the “G” terminal. This
motor may take a while to come to a complete
stop with selected delays.
If the above diagnostics do not solve the problem,
confirm the voltage checks in the next section
below, then continue diagnostics in the section,
“Model X13
®
& Endura
®
Pro Standard ECM Motor
Communication Diagnostics.” The TECINspect
®
Service Tool is not designed for use on this motor.
IF THE MOTOR IS NOT RUNNING
Check for proper high voltage and ground at the
(L)(G)(N) connections at the motor (see Figure
8 on the next page). Correct any voltage issues
before proceeding to the next step. The X13 &
Endura Pro motors are voltage specific. Only the
correct voltage should be applied to the proper
motor. Input voltage within plus or minus 10% of
the nominal 115VAC, 230VAC, 277VAC or 460VAC
1.
3.
4.
The TECINspect service tool is not needed for use
on this motor. If the motor has proper high voltage
and ground at the (L)(G)(N) connections, continue
diagnostics in the next section, “Model X13 &
Endura Pro Standard ECM Motor Communication
Diagnostics.”
2.
Always disconnect the power from the system before
removing the high voltage plug, and before reconnecting.
WARNING
To Next Page
