90
Autopilot
Panel
Joystick
Dual
Control
Ignition
Panel
Trim Tab
Switches
Dual
Plotters
Bow Thruster
Control
LX9 Helm Overview
The LX9 comes equipped with dual touchscreen
plotters and uses regal’s new digital switching
system to control electronic equipment around the
boat. Refer to the digital switching section in your
Ultimate Trim manual for more information.
The bow thruster joystick is used to control the
bow thruster (see “Thruster-Bow” pg. 151)
The Yamaha Dual Binnacle Control controls the
outboard engines.
The Yamaha Joystick is used to maneuver and dock
the vessel.
From the autopilot panel, you can control and
program the autopilot.
