18 | Regency
®
U39-12 ULTIMATE™ Freestanding Gas Stove
installation
Rigid Pipe Venting Arrangements
Vertical Termination Systems for
Residential Manufactured and
Mobile Homes
The shaded area in the diagram below shows all
allowable combinations of straight vertical and
offset to vertical runs with vertical terminations.
Maximum two 45
o
elbows.
If the vent is ENCLOSED in a chase (min. size 9"
x 9") maintain a 1-1/4" clearance to combustibles.
May be installed in Manufactured (Mobile)
Homes after first sale.
Horizontal Terminations for All
Venting Systems
The shaded areas in the diagram below show
all allowable combinations of vertical runs with
horizontal terminations. Maximum one 90
O
elbow
(two 45
o
elbows equal one 90
o
elbow).
Propane and Natural Gas:
Residential, Manufactured and
Mobile Homes Installations
May be installed in Manufactured (Mobile)
Homes after first sale.
Horizontal Run (Feet)
5'(1.5m) Min.
8'(2.4m)
5'(1.5m)
2' (.6m)
Min.
1'(0.3m)
10'(3m)Max.
13' (4.0m)
2
2
12
12
14
6
6
16
4
4
14
22
8
8
18
10
10
20
Vertical Height (feet)
20'-6"(6.2 )Max.m
Horizontal Run (Feet)
5'(1.5m) Min.
8'(2.4m)
5'(1.5m)
3' (.9m)
Min.
1'(0.3m)
10'(3m)Max.
13' (4.0m)
1
1
2
2
12
12
14
6
6
16
4
4
14
22
8
8
18
10
10
20
Vertical Height (feet)
20'-6"(6.2 )Max.m
0-2000'
NG - @38,000 Btu/hr #32
LP - @38,000 Btu/hr #49
0-4500'
NG - @35,000 Btu/hr #35
LP - @32,500 Btu/hr #51
