18
Regency E21 Gas Fireplace Insert
INSTALLATION
6)
Place Bottom Frame near hinge. Flip hinge over Bottom Frame and
secure with 3 screws each.
Bottom Frame
Hinge Location
5)
Install Spring Hinges to the Left and Right Side of the bottom of the
fi rebox using 2 screws per hinge.
7)
Install the Left and Right Side Screen Doors by placing over top of
the hinges on the faceplate.
Hold the door at a 45 degree angle to avoid scratching the
faceplate.
Hinge
Screen Door
8)
Close screen doors.
