19
Installer's Information
Remove 4x screws from the top of the appliance where shown.
Top of Appliance
1
Remove the 2 shipping brackets from the top edge of the glass by
removing the 4 screws. The 2 brackets can now be recycled. The 4
screws can then be reinstalled.
2
Carefully use the glass suction lifter provided to remove the glass
by lifting the pins clear of the slots on the front of the appliance.
3
1
2
Glass suction
lifter
4
Gently place the glass to one side.
Glass
Panel
5
To reinstall glass reverse steps 4-5.
The glass panel simply seats into the 4 slots as noted in above
diagram. Ensure the suction cup is safely stored away for future
use.
Note: The glass should only be installed once all the optional
accessories and media have been installed and appliance is in final
position.
REMOVAL INSTRUCTIONS
REMOVING GLASS FRONT
