Regency Insert & Hearth Heater 17
PARTS LIST - H2100
Part # Description Part # Description
1) 846-910 Door Assembly-Large Gold - no glass
846-916 Door Assembly-Large Black - no glass
3) 846-304 Glass - Replacement
4) 936-243 7/8" Adhesive Tape Gasket
5) 846-920 Glass Retainer Clips (set of 8)
6) * Screw 1/4-20 x 3/8"
7) 948-172/P Glass Retainer - Large
9) 846-973 Door Handle Assembly
16) 846-570 Med. Density Door Gasket Kit
17) 846-918 Hinge Caps (2/set)
19) 948-101 Spring Handle - Large
20) 948-102 Spring Handle - Small
120-915 H2100M Fan/Blower Assembly
24) 910-157/P Blower/Fan Motor (120 Volts)
25) 910-678 Power Cord (120 Volts)
27) 910-142 Fan Thermodisc
28) 910-140 Fan Speed Switch HI/OFF/LOW (3-way)
29) 910-138 Switch - Auto/Manual (2-way)
30) * Grommet Strain Relief
35) 120-954 Air Tube Front
36) 120-953 Air Tube Rear
37) 836-212 Baffle Insulation
38) * Insulation Weights
39) 120-950 Steel Baffle
948-216 Regency Logo
Faceplate: H2100M
120-910 Faceplate & Trim Set - Regular
485)120-161 Trim Right Regular
286) 143-158 Trim Top Regular
487)120-162 Trim Left Regular
488)* Faceplate Side Regular
489)* Faceplate Top Regular
120-912 Faceplate & Trim Set - Oversize
585)120-164 Trim Right Oversize
286)120-163 Trim Top Oversize
587)120-165 Trim Left Oversize
588)* Faceplate Side Oversize
589)* Faceplate Top Oversize
846-532 Trim Clips
836-300 Yellow Insulation 48" x 4"
846-531 Faceplate Hardware Pkg.
*Not available as a replacement part.
