MAIN CONTROL BOARD REMOTE RECEIVER BOARD REMOTE CONTROL
Hardware RC01-043A03 V0. RF290B V1.2 RF290A-TX V1.3
Software RC01-043A03 V0. - RF290C V06.0.HEX
Frequency - - ASK/OOK 433.92MHz
GB: Maximum Transmit Power - - 10mW
CONTROL SYSTEM TECHNICAL DATA
PACKING CHECKLIST
x2 (AAA)
LED Electric Fire Range
with Thermostatic Remote Control
Models: ES105, ES135, ES165
Instructions for Use, Installation & Servicing
For use in the US (United States) and CA (Canada)
IMPORTANT
THE HEATER OUTLET GRILLE BECOMES VERY HOT WHILE IN OPERATION. DO NOT COVER THE OUTLET GRILLE OR ANY
PART OF THE APPLIANCE. For use with 120V 60Hz electricity supply only. Please read these instructions carefully before
installation. Failure to follow them could result in serious injury. SAVE THESE INSTRUCTIONS: Leave this manual with
the appliance, they will be needed when maintenance or servicing is required. THIS APPLIANCE MUST BE GROUNDED
Studio
x1
x1
x1
x1
x10 (ST4x8)
x4 (ST4x12)
x4
x1
x4
x4 (Wood screws)
