REGULA 7027F - Page 11

11
air temperature from +5 to +40 ˚С;
relative air humidity from 35 % to 85 % at
the temperature of 25 ˚C;
atmospheric pressure from 630 to 800 mm Hg.
1.2.4 According to EIC, the device should not be
used in re risk and explosive conditions.
1.2.5 The main technical specications of the
device are given in Table 1.
Table 1
Parameters and Specications Value
IR light source peak wavelength (for
Regula 7027F.100 and 7027F.110), nm
1)
870±20
UV light source peak wavelength (for
Regula 7027F.110), nm
1)
365±2
Color of the visible light sources
1)
white
Field of view (horizontal x vertical), mm 128×87
Frame size, dots(pixels)
1)
2592×1944 (5 Mp)
Connection interface USB 2.0
Power supply voltage (via the USB port
of the PC), V
5±0,2
Rated current consumption, A, max 0,9
Device weight, kg, max 0,8
Device dimensions, mm, max 148×208×95
RFID Frequency band, kHz 13 553–13 567
Max power < 60 dΒuΑ/m@10mt
1) — Light source and camera parameters correspond
to manufacturer’s specications.
