HOW THIS BLOOD PRESSURE MONITOR WORKS
This monitor uses innovative technology to detect your
blood pressure. This technology enables the monitor to
automatically inflate and deflate at the appropriate level
for each individual. With one touch of a button, the cuff
will automatically inflate to block the blood flow through
your artery. Next, the deflation process starts. Please note
that any muscle movement during inflation or deflation
will cause measurement error. When measurement is
complete, the monitor will display your systolic pressure,
diastolic pressure, and pulse readings.
The monitor automatically finds where your measurement
results fall on the NIH’s National Heart Lung and Blood
Institute’s table and provides a cue if your reading falls into
one of the stages that could potentially indicate increased
risk. Please refer to page 20 for more information on this
feature.
The appearance of the
icon indicates that a pulse
irregularity consistent with an irregular heartbeat was
detected during measurement. Refer to page 21 for more
information on the Irregular Heartbeat Detector.
NAME/FUNCTION OF EACH PART
Air Tube
and Connector
Arm Cuffs
Other Accessories:
1 6V DC Output AC Adapter
4 “AA” size, 1.5V alkaline batteries (not included)
Note: Please unload the batteries when operating
with the AC adapter for an extended period of time.
Battery
Cover
USER-SELECT
Button
START/STOP Button
MEMORY RECALL Button
( Located
on bottom
of unit)
DATE/TIME
Set Buttons
LCD Display
