3
ENGLISH
SCOPE OF DELIVERY
- Mixon 4 controller
- Power supply unit
- USB cable
- iOS connection cable
- OTG USB cable
SETUP AND CONNECTIONS
1. Connect your output devices (headphones, speakers, etc.) to the Mixon 4. Audio output takes place via the master output (XLR and RCA) and the booth output.
2. Connect your input devices (microphone, turntable* or CD player*) to the Mixon 4. The microphone input takes place directly on the master channel.
3. Make sure that the Mixon is turned off and that the master and booth faders are in the 'min' position.
4. Connect all devices to a power outlet and turn them all on.
5. If you wish to use the Mixon 4 with Serato, please refer to the installation instruction further below for your next steps. If you wish to use djay, please also refer to the installation instruction
further below for your next steps.
*The input with turntable (PHONO) and CD player (LINE) only supports usage with DVS. The signal is routed 1:1 to the USB port and it cannot be heard via the master output.
Master PA / Active Speakers
MIC
Headphones
6.3 mm jack
6.3 mm jack
3.5 mm jack
XLR
RCA
RCA
RCA
USBUSB
PSU
PC / MAC
Lightning
GND
OTG
1/4 Jack
Active DJ Monitors
DVS Player 2
(Turntable / CD-Player)
DVS Player 1
(Turntable / CD-Player)
iOS Devices Android Devices
HiFi Stereo System / Powered Loudspeakers
