8
NO. CONTROL / ELEMENT SERATODJ DJAY PRO
39a MST OUT (XLR) Master Volume Output (XLR) -> Controlled by no. 10
39b MST OUT (RCA) Master Volume Output (RCA) -> Controlled by no. 10
40 BOOTH OUT (RCA) Booth Volume Output -> Controlled by no. 10
Same output as for Master out
41 PH/LN INPUT SW Selects input source.
42 DVS INPUT (RCA) RCA input for DVS control of DECK 3 & DECK 4*2
43 iOS CONNECTION Connection for iPad/iPhone device
Only lightning generation is supported
iOS device will be charged through the controller
USB and iOS can't be used at the same time. Only one connection
can be active.
44 USB INPUT USB connection to PC/MAC
45 HEADPHONES OUT 3,5 mm & 6,3 mm Output
46 MIC INPUT Microphone Input 6,3 mm. The audio signal from the microphone is
routed directly to the master output.
47 MIC VOL Microphone Input GAIN adjust
48 POWER Power On/Off. Device requires external power supply.
*1: Requires Serato Pitch 'n Time plugin.
*2: Requires Serato DVS Expansion Pack. Not available for djay Pro.
*3: Requires Serato Flip Expansion Pack
*4: Only available for djay Pro (Mac Edition)
Reloop also offers support for third-party suppliers such as VirtualDJ and Traktor Pro. ASIO drivers, rmware updates and current mappings can be downloaded under www.reloop.com
