Reloop RMX90DVS User Manual

MIDI MAP
46
SECTION ITEM TYPE MIDI (HEX) MIDI 2 (DEC)
CH1 INPUT SW 9n 01 CD = 0, USB = 64, LINE = 127
GAIN VR Bn 01 0-127
HIGH VR Bn 02 0-127
MID VR Bn 03 0-127
LOW VR Bn 04 0-127
FILTER VR Bn 05 0-127
CUE BTN 9n 02 OFF = 0, ON = 127
Channel Fader VR Bn 06 0-127
CF ASSIGN SW 9n 03 A = 0, T = 64, B = 127
CH2 INPUT SW 9n 04 CD = 0, USB = 64, PH = 127
GAIN VR Bn 07 0-127
HIGH VR Bn 08 0-127
MID VR Bn 09 0-127
LOW VR Bn 0A 0-127
FILTER VR Bn 0B 0-127
CUE BTN 9n 05 OFF = 0, ON = 127
Channel Fader VR Bn 0C 0-127
CF ASSIGN SW 9n 06 A = 0, T = 64, B = 127
CH3 INPUT SW 9n 07 CD = 0, USB = 64, PH = 127
GAIN VR Bn 0D 0-127
HIGH VR Bn 0E 0-127
MID VR Bn 0F 0-127
LOW VR Bn 10 0-127
FILTER VR Bn 11 0-127
CUE BTN 9n 08 OFF = 0, ON = 127
Channel Fader VR Bn 12 0-127
CF ASSIGN SW 9n 09 A = 0, T = 64, B = 127
CH4 INPUT SW 9n 0A CD = 0, USB = 64, LINE = 127
GAIN VR Bn 13 0-127
HIGH VR Bn 14 0-127
MID VR Bn 15 0-127
LOW VR Bn 16 0-127
FILTER VR Bn 17 0-127
CUE BTN 9n 0B OFF = 0, ON = 127
Channel Fader VR Bn 18 0-127
CF ASSIGN SW 9n 0C A = 0, T = 64, B = 127
CROSSFADER CROSSFADER VR Bn 19 0-127
MASTER MASTER VOL VR Bn 1A 0-127
MASTER BAL VR Bn 1B 0-127
BOOTH VR Bn 1C 0-127
BOOTH SW SW 9n 0D MN = 0, SR = 127
CUE BTN 9n 0E OFF = 0, ON = 127
EQ CURVE SW 9n 0F KILL = 0, CLASSIC = 127
FADER CURVE CHANNEL CURVE VR Bn 1D 0-127
CF CURVE VR Bn 1E 0-127
FADER START CHANNEL START BTN 9n 10 OFF = 0, ON = 127
CF START BTN 9n 11 OFF = 0, ON = 127
FS CH 1 BTN 9n 12 FADER DOWN = 0, FADER UP = 127
FS CH 2 BTN 9n 13 FADER DOWN = 0, FADER UP = 127
FS CH 3 BTN 9n 14 FADER DOWN = 0, FADER UP = 127
FS CH 4 BTN 9n 15 FADER DOWN = 0, FADER UP = 127
EFFECTS CUE BTN 9n 16 OFF = 0, ON = 127
BEAT FX ENC Bn 1F 63~54
BEAT FX (push) SW 9n 28 OFF = 0, ON = 127
CH SELECT SW 9n 17 CH 1, OFF = 0, ON = 127
SW 9n 18 CH 2, OFF = 0, ON = 127
SW 9n 19 CH 3, OFF = 0, ON = 127
SW 9n 1A CH 4, OFF = 0, ON = 127
SW 9n 1B MIC, OFF = 0, ON = 127
SW 9n 1C CF A., OFF = 0, ON = 127
SW 9n 1D CF B., OFF = 0, ON = 127
SW 9n 1E MASTER, OFF = 0, ON = 127
TIME ENC Bn 20 63~54
BPM TAP BTN 9n 1F OFF = 0, ON = 127
LEVEL DEPTH VR Bn 21 0-127
FX ON BTN 9n 20 OFF = 0, ON = 127
BEAT (-) BTN 9n 21 OFF = 0, ON = 127
BEAT (+) BTN 9n 22 OFF = 0, ON = 127
MIC/AUX SOURCE SW 9n 23 AUX = 0, MIC = 127
MIC/AUX LEVEL VR Bn 22 0-127
MIC2 LEVEL VR Bn 23 0-127
HIGH VR Bn 24 0-127
LOW VR Bn 25 0-127
ON/OFF/TLKOVR SW 9n 24 OFF = 0, ON = 64, TLKOVR = 127
CUE BTN 9n 25 OFF = 0, ON = 127
HEADPHONE SPLIT SW 9n 27 OFF = 0, ON = 127
CUE EQ VR Bn 26 0-127
CUE MIX VR Bn 27 0-127
CUE LEVEL VR Bn 28 0-
127
8. MIDI MAP
