17. USB Rec. Port
ConnectaUSBstoragedevice(USBstick)tothisport,incaseyouwouldliketocreatearecord-ing.
18. Headphones Out (3.5 & 6.3 mm Jack)
Pluginheadphoneswith3.5or6.3mmjackstothisconnection.
NOTE: When headphones are connected, the speaker will be muted.
19. Master Out (RCA)
ConnectReloopSPINtoasoundsystemviathisconnection(RCA).
NOTE: When a cable is connected to the Master Output, the speaker will be muted.
20. On/Off Button
Viathisbuttonyoucanturnon/offyourReloopSpin.
21. USB PSU Input
ConnectaregularUSBPSU(notincludedinthescopeofdelivery)tothisconnectionandapoweroutlet.
22. Battery Compartment
Optionally you can operate Reloop SPIN with 2 Lithium Ion
18650batteries.Todoso,openthiscompartmentandinsertto
fully loaded batteries.
NOTE: Further information can be found in chapter “V. Opera-
tion/Power Supply” in this in-struction manual.
23. Aux In (3.5 mm Jack)
Connectyouraudiosourcetothisconnectionvia3.5mmjack.
24. Speaker
YourReloopSPINturntabledisposesofanintegrated3-wattsspeakerforplayingrecords,play-backdevicesconnectedtoAux-InandBluetooth
audio signals.
NOTE: This integrated speaker will be muted when either Master Out -19- or one of the Headphones Outputs -18- is used.
IV. CROSSFADER
It is possible to replace the crossfader or install it in the alternate holder, in order to use your preferred crossfader side.
Installing the crossfader in alternate compartment
First remove the crossfader cap. Then unscrew the 2 outer
screws. The crossfader can now be pulled out of the compart-
ment. Gently remove the cable connector from its socket on the
pcb.Unscrewthe2screwsofthealternatecrossfadercompart-
ment and remove the cover. Now place the crossfader with its
cover into the alternate compartment and x it with the two
screws. You will nd the necessary cable for connecting the
crossfader in the compartment.
Replacing the crossfader (1)
First remove the crossfader cap. Then unscrew the 2 outer screws.
The crossfader can now be pulled out of the compartment. Gently
remove the cable connector from its socket on the pcb.
Unscrewthetwoscrewsfromthecrossfadercover.Replacethe
crossfaderandxitwithitscoverbytighteningallscrews.
NOTE!
In both compartments you can nd an additional cable (2)
which is intended for connection of third-party crossfaders
(digital).
(1)
(2)

Reloop SPIN Specifications

General

Drive Type	Belt Drive
Speed	33 1/3, 45, 78 RPM
Bluetooth	No
Speaker	Built-in speaker
Type	Portable turntable
Motor	DC Motor
Platter Diameter	12 inches
Outputs	RCA
Battery	Yes
