9
ENGLISH
INCLUDED ACCESSORIES:
Turntable Platter
Dust Cover
2x Dustcover hinges
Balance Counter Weight
PHONO RCA Cable with earth lead
AC power supply cord
Rubber Mat
Instruction Manual
Ortofon 2M Red cartridge & headshell
DESIGNATION
1. Turntable
2. Hub
3. ON/OFF Button on Turntable Illumination
4. START/STOP Button
5. 33/45/78 Switch
6. Headshell incl. Ortofon 2M Red
7. Tone Arm
8. Tone Arm Ring
9. Tone Arm Rest
10. Tone Arm Lift
11. Anti-Skating Wheel
12. Tone Arm Ring Locking Mechanism
13. Counterweight Scale
14. Counterweight
15. Audio Output (Cinch)
16. Ground Screw (GND)
17. Voltage Selector Switch
18. Mains Cable Connection
19. Turntable Cover Mount
1
2
3
4
4
5
6
7
8
9
10
11
12
14
13
15 16 17 18
19 19

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Reloop TURN 5 and is the answer not in the manual?

Reloop TURN 5 Specifications

General IconGeneral
Drive TypeDirect Drive
PlatterDie-cast aluminum
Speed33 1/3, 45, 78 RPM
CartridgeOrtofon 2M Red
Phono OutputYes
Braking SystemElectronic brake
Platter Diameter332 mm
Tonearm Effective Length230 mm
Overhang15 mm
Tracking Force Adjustment Range0 - 4 g
Anti-Skating Range0 - 4 g
Line OutputYes
USB OutputYes
Power SupplyAC 115/230 V, 60/50 Hz
Tonearm TypeStatic balanced S-shape
Braking Time< 1 second
Applicable Cartridge Weight3.5 - 8.5 g
USBUSB 2.0
Pitch Control+/-8%, +/-16%
Wow and Flutter0.01% WRMS
