11
ENGLISH
TECHNICAL SPECIFICATIONS
Turntable Section:
Type: ...................................................................................................... Direct Drive Manual Turntable System
Drive: ..................................................................................................... Quartz driven upper-torque direct drive
Motor: ....................................................................................................16pole, 3phase, brushless DC motor
Turntable Speeds: ............................................................................... 3 speeds, fully manual (33 1/3, 45, 78 rpm)
Starting Torque: ..................................................................................4500 gf.cm
Start-up time / rpm change: .............................................................less than 0.2 sec.
Wow and utter: .................................................................................. 0.01% WRMS*
S/N Ratio: ............................................................................................. More than 55dB (DIN-B)
Brake system: ...................................................................................... electronic brake,
*Impact of stylus, record and tone arm not taken into account
Turntable Platter:
Material: ................................................................................................aluminium die-cast
Diameter: ..............................................................................................332mm
Weight: .................................................................................................. approx. 1.8kg (including rubber mat)
Tonearm Section:
Type: ...................................................................................................... Universal Static Balanced S-Shaped
Effective Length:.................................................................................230mm
Overhang: ............................................................................................. 15mm
Tracking Error Angle: ......................................................................... Less than 3 degree
VTA Adjustment Range: .................................................................... 0-6 mm
Anti-Skating Range: ...........................................................................0 – 3g
Effective tonearm mass: ...................................................................20g
Terminals: ............................................................................................. 1x PHONO Out (gold-plated), 1x GND Earth Terminal
General:
Power supply: ......................................................................................AC 115/230 V, 60/50 Hz (EU/US), AC 100 V, 50/60 Hz (JP)
Power Consumption: ..........................................................................9W
Dimensions: ..........................................................................................458 (W) x 368.3 (D) x 162.4 (H) mm
Weight: .................................................................................................. approx. 12.8kg
Cartridge Ortofon 2M Red :
Output voltage at 1000 Hz, 5cm/sec.: ............................................5,5 mV
Channel balance at 1 kHz:..................................................................1,5 dB
Channel separation at 1 kHz: ............................................................ 21 dB
Channel separation at 15 kHz: .......................................................... 15 dB
Frequency range at – 3dB: ................................................................20-22.000 Hz
Frequency response: ..........................................................................20-20.000 Hz
Tracking ability at 315 Hz at recommended tracking force: .......70 µm
Compliance, dynamic, lateral: ...........................................................20 µm/mN
Stylus type: .......................................................................................... Elliptical
Stylus tip radius: ................................................................................. r/R 8/18 µm
Tracking force range: ......................................................................... 1,6-2 g (16-20 mN)
Tracking force, recommended: ......................................................... 1,8 g (18 mN)
Tracking angle: .................................................................................... 20°
Internal impedance, DC resistance: .................................................700 mH
Internal inductance: ...........................................................................47 kOhm
Recommended load resistance: ....................................................... 47 kOhm
Recommended load capacitance: ....................................................150-300 pF
Cartridge colour, body/stylus: ..........................................................Black/Red transparent
Cartridge weight Headshell included: ............................................. 20 g
Length headshell with 2M cartridges pre-mounted: .................... 52 mm (Baerwald)
Replacement stylus unit: ...................................................................2M Red
Note: Subject to alterations. The specied data is of approximate value.
Reloop Distribution
Global Distribution GmbH
Schuckertstrasse 28
48153 Muenster / Germany
Fax: +49.251.6099368
Subject to alterations.
Illustrations similar to original product.
Misprints excepted.
