A. Information on installation
Step 2: (Installing the guidings)
Step 1: (Check content of delivery)
A3
A1
A2
A1+A2:
Content: 1x preinstalled coffer with upper guiding prole
and oor prole (see A1)
1x shutter
1x pinhole panel
1x preinstalled angle bracket
2x cheesehead screw 2.9x19
Note: We recommend to install the insect protection door with 2 people.
For a full install, you will need the following additional xation material:
(A) 5x countersunk bolt 2.9x16
(B) 2x panhead bolt 3.5x16
(C) 5x panhead bolt 3.5mm (length depends on the furniture
construction)
A3:
First fold the upper guide and the oor prole by 90°. Make sure that the
cords do not twist. We recommend assembly on a at surface.
