MEGANE CABRIOLET NU 640-2
C:\Documentum\Checkout\nu640-2_eng_T5.WIN 24/2/2001 14:44
-page16
5.16
FUSES
Fuse box 1
If an incident occurs in an electrical
component, check first of all that
the fuses are sound. Also make sure
that the faulty component is
correctly connected. If a short
circuit occurs, unscrew one of the
wing nuts on the battery posts to
isolate the battery.
Open the cover 2 (under the steering
wheel).
To identify the fuses, refer to label 4
(shown on the page opposite).
It is advisable not to use the free
fuse locations.
Check the fuse in
question and replace it,
if necessary, with a fuse
which must be of the
same rating as the original fuse
If a fuse is fitted where the rating
is too high, it may cause the
electrical circuit to overheat (risk
offire)intheeventofanitemof
equipment using an excessive
amount of current.
CORRECT INCORRECT
Use tweezers 3 to remove the fuse.
Toremovethefusefromthe
tweezers, slide the fuse to the side.
A wise precaution:
Obtain a box of spare bulbs and
fuses from your Renault Dealer.
