Renault 2013 Clio Cup - B.6.4 Basic Procedures; B.6.4.1 P Ower - up

98CUP_2013 Release
C-22
B
" Manifold P - def"
+ value in Blue
1 Left Electrical fault on manifold sensor -
B
"Oil P - def"
+ value in Blue
1 Left
Electrical fault on oil pressure sensor -
B
"Water T - def"
+ value in Blue
1 Left
Electrical fault on water temperature sensor -
B
“Throt FBW * def”
+ value in blue
1 Left
Electrical fault on motorised throttle
B
“High press def”
+ value in Blue
1 Left
High pressure sensor default -
B
“Low press def”
+ value in Blue
1 Left
Low pressure sensor default -
B
" V.V.T.1 - def"
+ value in Blue
1 Left Intake V.V.T. servo control default
difference > 10°
between
VVT1_tg and
VVT1_pos during
more than 5s
B
“GB actuator - def”
+ value in Blue
1 Right Gearbox actuator default (only if connected) -
B
"GB Pot - def"
+ value in Blue
1 Right Electrical default on barrel position sensor -
B
“up contact – def”
+ value in Blue
1 Right Electrical default on upshift contactor -
B
“Solenoid R”
+ value in Blue
1 Right
Electrical default on reverse solenoid (barrel
unlocking)
-
B "CBNT - Can Def" - CAN CBNT fault -
B "Steering - def" - Major/minor fault on power steering module -
“Gear” -
Gear button pressed, message displayed in the
middle of the screen without alarm
"Pit Limiter" -
Speed limiter enabled, message displayed
on the top
of the screen without alarm
-
B.6.4 BASIC PROCEDURES
B.6.4.1 Power-up
Press the “ON” button of the facia switch panel (See B.6.1) to power supply the vehicle
The “COSWORTH” home page appears when the dashboard display first comes on, and
then moves to the first driver page (RACE Page)
B.6.4.2 Starting
Once the vehicle’s electrics are on, flick the vehicle's “IGNITION” switch to the up (ON)
position.
Check that no gear is engaged (the letter “N” is displayed on one of the display screen’s
driver pages).
Press on the “START” button without touching the Gas Pedal
The vehicle will only start if the following electronic equipments are connected
and are working properly:
- ECU
- CBNT
- Master relay
It is possible to start without plugging the dashboard
NOTE : For the first engine start after engine refitting, it’s necessary to bleed the fuel
rail. To make it properly, please follow carefully the procedure indicated in chapter C-
Engine
