5.13
REAR LIGHTS: replacing bulbs
Remove the screw 1 and pull off the
rear light cluster from the outside.
Unclip the bulb holder by moving
the tab 2.
3 Tail light and stop light
Pear-shaped bulb, bayonet type
with 2 filaments, P 21/5 W.
4 Reversing light (right-hand side)
Pear-shaped bulb, bayonet type
with 2 filaments P 21 W.
5 Direction indicator
Pear-shaped bulb, bayonet type,
orange, P 21 W.
6 Fog light (left side)
Pear-shaped bulb, bayonet type
with 2 filaments P 21 W.
