CHILD SAFETY (continued)
A forward-facing Isofix seat
fitted on the rear side seat
When a forward-facing child seat is
installed, the front seat must not be
moved back beyond the halfway point
on the seat runners and the seatback
must not be reclined too far.
Each of the rear seats is fitted with two
rings for mounting the base of the seat.
Mounting ring for a forward-
facing seat
Use belt 4 supplied with the seat:
– pass belt
4 between the two rear
headrest rods;
– attach hook
5 to ring 6 located in the
luggage compartment;
– tighten the belt.
A rear-facing Isofix seat fitted
on the rear side seat
When a rear-facing child seat is in-
stalled, the front seat must not be
moved forward beyond the halfway
point on the seat runners.
The front seatback must be close to or
touching the shell of the child seat.
Use belt 4 supplied with the seat:
– fix hook
5 on ring 7 located under the
front passenger seat;
– tighten the belt.
5
6
4
4
5
7
