Aérateurs (sorties air) (XJA - Renault)
Centre 4 and side vents 1
and 6
Air flow
To close: move the cursor 10 towards
the outside of the vehicle beyond the
resistance point.
To open: move the cursor 10 towards
the inside of the vehicle.
Direction
Move the cursor 10 to the desired po-
sition.
AIR VENTS, air outlets (2/2)
6
10
Do not add anything to the
vehicle’s ventilation circuit
(for example, to remove
bad odours).
There is a risk of damage or of
fire.
4
9
Rear seats
(depending on vehicle)
Passenger footwell heater outlets 9.
Do not attach any objects to the air
vents (e.g. telephone mounting).
Risk of damage.
