Renault Clio - Wiper Blades: Replacement

windscreen washer/wiper
replacing blades ...................................
(up to the end of the DU)
windscreen washer/wiper ..........................
(up to the end of the DU)
5.33
ENG_UD62013_3
Balais d essuie-vitres (BJA - Renault)
Wiper blades: replacement
WIPER BLADES: replacement (1/2)
Replacing the windscreen
wiper blades 2
To replace the wipers, first put them in
the service positionB.
With the engine running or the igni-
tion on:
– set the stalk 1 to position A twice in
succession (single sweep): the wiper
blades will stop in position B away
from the bonnet;
– lift the wiper arm 3;
– lower the 4 tab then remove the
blade 2.
3
2
4
To refit
To refit the wiper blade 2, insert it in its
housing in the arm 3, then clip it until
you hear a click. Make sure that the
blade is correctly locked in position.
To return the blades to lowered posi-
tion, make sure that the blades are
folded down onto the windscreen then
set the 1 stalk to position A (single
sweep): the windscreen wiper blades
will fold into the bonnet when the igni-
tion is switched on.
1
A
B
Check the condition of the wiper
blades. You are responsible for their
service life:
– clean the blades, windscreen and
rear screen regularly with soapy
water;
– do not use them when the wind-
screen or rear screen are dry;
– free them from the windscreen or
rear screen when they have not
been used for a long time.
