Fusibles (BJA - Renault)
FUSES (3/4)
Allocation of fuses
(the presence of certain fuse depends on the vehicle equipment level)
Symbol Allocation
H
Windscreen washer
î
Multimedia accessories socket, multimedia
screen
Æ
Front and rear second row accessories socket
Ì
Horn
Ý
Towbar socket
Heated rear view mirrors
×
Brake lights, passenger compartment central unit
Passenger compartment centre unit, rear wiper,
rear fog light
D
Direction indicator lights, hazard warning lights,
high level brake lights
Use the fuse allocation label in the
storage compartment to identify the
fuses.
Certain fuses should only be re-
placed by a qualified professional.
These fuses are not listed on the
label.
Only change the fuses represented
on the label.
