Carte : généralités (HFE - Renault)
Fitting a hand strap 7
Slide the rear casing 5 downwards
while pressing on zone A.
Insert the hand strap into the 8 com-
ponent and pass the end of the strap
through the buckle.
Position the strap at the 6 opening and
close the cartridge.
Note: check that the diameter of the
hand strap cord 7 will fit the opening 6.
Never insert screwdriver-type tools
into the 6 opening.
CARD: general information (3/3)
8
A
5
6
7
