Renault LAGUNA 2000 - Page 27

VALUES AND SETTINGS
Procedure for tensioning the timing belt
07
07-10
F9Q engine
Connect the sensor of Mot. 1505.
Tighten the belt until you reach the recommended fitting value of 88 ± 3Hz by
tightening the bolt (2).
Tighten the tensioner to a torque of 1 daNm.
16151-5R1
Turn the crankshaft two revolutions.
