VALUES AND SETTINGS
Procedure for tensioning the timing belt
07
07-21
F4P engine
Method for undoing the exhaust camshaft pulley
and the inlet camshaft dephaser.
The operation is performed using tools Mot. 1509
and Mot. 1509-01.
Remove the upper toothed pinion from the bracket.
