VALUES AND SETTINGS
Procedure for tensioning the timing belt
07
07-37
F4P engine
NOTE: do not rotate the tension wheel in an anti-
clockwise direction.
Align the marks (6) and (7) of the tension wheel, using
a 6 mm Allen key in (B).
Pre-tighten the tension wheel nut to a torque of
0.7 daNm.
Tighten the bolt of the accessories crankshaft pulley to
a torque of 2 daNm (Top Dead Centre pin Mot. 1054
still positioned in the crankshaft).
