E1/E20/E2/E2 Lite Additional Document 2. Designing the User System
R20UT1994EJ0900 Rev.9.00 Page
34
of 58
Jan.20.22
Emulator
control
circuit
3 MW
RSTPU
VDD
4
8
3.3 V
EMVDD
TOOL0
5
EMVDD
6
RESET_IN
47 W
10
RESET_OUT
3.3 V
100 kW
GND
14
13
RESET_OUT
47 W
2,12
GND
Power-supply circuit
(only for use in the mode to
supply power to the user
system)
EMVDD
EMVDD
9
47 W
1 MW
74LVC1T45
74LVC1T45
74LVC1T45
74LVC1T45
74LVC1T45
0.1 F
74LVC8T245
74LVC1T45
74LVC8T245
74LVC8T245
74LVC1T45
47 W
74LVC1T45
User-side
connector
1 MW × 2
100 kW
47 W
47 W
Self-recovering
fuse
Figure 2-19 Internal Circuits of the E2 (Rev. D)
Set the switch on the 20-pin (1.27-mm pin spacing) to 14-pin (2.54-mm pin spacing) connector conversion
adapter to position “3”.
