Switch
On Setting (white bar) (default)
Off Setting
SW7
RXCLK5 from Phy
RXCLK5 from GPIO61
Table 4: Jumper Settings RZ/N1S-DB
USB Power
Jumper
On Setting (default)
Off Setting
CN14
Power from USB
Power from expansion board
SRESET from Debugger to RZ/N1D
Jumper
On Setting (default)
Off Setting
CN10
RZ/N1D is connected with the
SRESET from the Debugger
Debugger cannot reset the CPU
MRESETout
Jumper
On Setting
Off Setting (default)
CN9
MRESETOUT is connected to
the Debugger
Debugger cannot detect any
internal CPU reset
USB Host/Device Mode
Jumper
On Setting
Off Setting (default)
CN2
OTG mode ID
Peri Mode ID
Table 5: Push buttons
SW2:
Boot Mode Select
In case SW3 (2) has selected QSPI it is possible to boot from USB instead of the QSPI if SW2 is
pressed down during RESET.
Switch
On Setting
Off Setting
SW2
Boot from USB
Boot from QSPI
Table 6: Reset and NMI Button
SW8
