Renogy 200W User Manual

15
Battery Charging Parameters
Battery
GEL
SEALED
FLOODED
High Voltage
Disconnect
16 V
16 V
16 V
Charging Limit Voltage
15.5 V
15.5 V
15.5 V
Over Voltage
Reconnect
15 V
15 V
15 V
Equalization Voltage
-----
14.6 V
14.8 V
Boost Voltage
14.2 V
14.4 V
14.6 V
Float Voltage
13.8 V
13.8 V
13.2 V
Boost Return Voltage
13.2 V
13.2 V
13.2 V
Low Voltage Reconnect
12.6 V
12.6 V
12.6 V
Under Voltage Recover
12.2 V
12.2 V
12.2 V
Under Voltage Warning
12 V
12 V
12 V
Low Voltage Disconnect
11.1 V
11.1 V
11.1 V
Discharging Limit
Voltage
10.8 V
10.8 V
10.8 V
Equalization Duration
-----
2 hours
2 hours
Boost Duration
2 hours
2 hours
2 hours
Charging Parameters Glossary
High Volt Disconnect—users can use the default parameters or assign a rated voltage value
that the charge controller will operate. When and if the charge controller experiences a voltage
higher than what is assigned, it will disconnect itself from the circuit; ceasing charge.
Charging Limit Voltage—depending on the batteries used, there might be a battery charging
limit voltage that is recommended for the battery. This parameter ensures that the charge
controller does not exceed the default or assigned rated charging limit voltage. This is usually
put into play to optimize and extend the life of the battery. Relatively speaking, the higher the
charging voltage then there is a correlation for reduced battery efficiency. (Likewise the lower
the discharge voltage affects battery efficiency.
Over-voltage Reconnect—In the event a charge controller experiences an over-voltage
condition set by the previous two parameters, then this reconnecting parameter is put into play
to direct the controller when it can connect and safely charge again. Typically over-voltage
reconnection is achieved when time has passed (ex. The sun setting), or when the over-voltage
condition is remedied ultimately reducing the voltage to a user defined charging voltage.
Equalization Voltage—equalization voltage is a corrective over-charge of the battery. The user
should consult their battery manufacturer regarding specific battery equalization capacity. This
parameter sets the equalization voltage to set the battery at when it reaches the equalization
state.

Renogy 200W Specifications

General

Maximum Power Output	200W
Cell Type	Monocrystalline
Weight	26.5 lbs
Module Efficiency	21%
Maximum System Voltage	600V DC
Operating Temperature	-40°F to 185°F
Warranty	25 years
Cable Length	35.4 inches (900mm)
