Renogy 200W User Manual

14
Technical Specifications
Solar Panel Parameters
Description
100 W Parameters
200 W Parameters
Maximum Power
100 W
200 W
Open Circuit Voltage (Voc)
21.6 V
21.2 V
Short Circuit Current (Isc)
6.10 A
11.72 A
Maximum Power Voltage (Vmp)
17.6 V
17.7 V
Maximum Power Current (Imp)
5.68 A
10.35 A
Cell Type
Monocrystalline
Monocrystalline
Operating Temperature
−40°F to +185°F
−40°F to +185°F
Folded Size
21.1 X 21.5 X 3.1 in
41.3 X 21.1 X 3.1 in
Net Weight
19.40 lbs.
33.60 lbs.
Charge Controller Parameters
Description
Parameter
Nominal Voltage
12 VDC
Rated Charge Current
30A
Max. PV Input Voltage
25 VDC
Equalization Voltage
Sealed: 14.6 V; Gel: None; Flooded: 14.8 V
Boost Voltage
Sealed: 14.4 V; Gel: 14.2 V; Flooded: 14.6 V
Float Voltage
13.8 V
Under Voltage
12 V
Self-consumption
≤13mA
Temperature Compensation
Coefficient
-3mV/℃/2V
Operating Temperature
-25℃ to +55℃ | -13
o
F to 131
o
F
Storage Temperature
-35℃ to +80℃ | -31
o
F to 176
o
F
Enclosure
IP20
Terminals
Up to #4 AWG
Weight
0.6 lbs.

Renogy 200W Specifications

General

Maximum Power Output	200W
Cell Type	Monocrystalline
Weight	26.5 lbs
Module Efficiency	21%
Maximum System Voltage	600V DC
Operating Temperature	-40°F to 185°F
Warranty	25 years
Cable Length	35.4 inches (900mm)
