20
The arrow only displays during
startup and not part of the solar
inverter functionality
Indicates that the charging circuit
is charging the battery
1
Indicates that the power utility/grid
is powering the battery charging
circuit (AC-DC)
Indicates that the battery is
powering the inverter circuit
(DC-AC)
3
5
Indicates that the utility/grid is
powering the load
The arrow only displays during
startup and not part of the solar
inverter functionality
2 6
7
Indicates solar (PV) power to the
battery charging circuit (DC-DC)
Indicates that the inverter circuit is
powering the load
4 8
1
2
3
4
65 7 8
40
21
1
20
