Renogy Monitoring Screen User Manual

07
Dimensions
110.0mm
4.3in
87.5mm
3.4in
1.3in
0.8in
2.8in
70.0mm
2.3in
58.5mm
31.8mm
19.5mm
Additional Components
RJ45 Communication Cable
The RJ45 Communication
Cable (5m/16.4ft) is used to
connect the monitoring
screen to the battery bank
for power supply and data
transmission.
Self-tapping Screws (4)
The Self-tapping Screws
(M2.9x13) are used to fix
the monitoring screen on
the mounting surface.

Renogy Monitoring Screen Specifications

General

Brand	Renogy
Model	Monitoring Screen
Category	Measuring Instruments
Language	English
