Renogy MT-150 - System Status Troubleshooting

9
System Status Troubleshooting
Meter not turning on
Make sure the connections are properly secured onto the LOAD and SOURCE side of
the meter. If so, disconnect all connections and connect again to resume proper
operation.
Display is dim
Might be due to low voltage. Check to make sure your battery or auxiliary battery have at
least 4.8V connected to the SOURCE side.
Wiring is warm
It is normal for the MT-150 to get warm during high currents. You can cool it with a small
fan.
CAUTION: Make sure connections are secure and expose no wire that may short. Also
make sure operation does not exceed rated technical specifications.
Technical Specifications
Description
Parameter
Operation Voltage:
7 - 55V
Operation Amperage
50A Max; 150A Peak (surge)
Auxiliary Battery Operating Voltage
0 – 60 V
Measurement Resolution:
0 – 150A, 0.01 A Resolution
0 – 60 V, 0.01 V Resolution
0 – 9000 W, 0.1 W Resolution
0 – 65 Ah, 0.001 Ah Resolution
0 – 9000 Wh, 0.1 Wh Resolution
LCD Display
62 x 12.5 mm (2.44 x 0.49 in)
Dimensions:
85 x 45 x 25 mm (3.35x1.77x0.98 in)
Weight
82 g (0.18lbs)
Wire Size
12 AWG
