Identification of Parts
Key Parts
1. Source Side Connection
2. Load Side Connection
3. Negative Wire
4. Positive Wire
5. Auxiliary Battery Port (Optional Component)
Installation
WARNING: Poor connections and reckless wiring can have serious consequences
including personal injury, electrical shock, and may cause a fire.
CAUTION: Make sure connections are secure and expose no wire that may short.
NOTE: The user is responsible for attaching connectors that are rated to handle the
expected voltage and current limitations.
1. Connect the Positive (+) and Negative (-) leads of SOURCE to the battery or other device’s
terminals.
2. Connect the Positive (+) and Negative (-) leads of LOAD terminals to a device to complete
the circuit.
