26
Remove bolt and washer with
the Allen key provided (make
sure the springwasher stays
on the bolt). (1)
Select required attachment for
the job, place the attachment
on top of the octagonal face of
the tool making sure that both
octagonal faces are ush and
rm with each other. (2)
Place bolt and washer back
on the tool. (3) (make sure
the springwasher is on the
bolt and ts nicely on top the
washer - see page 18 for more
information)
Tighten the bolt using the
supplied Allen key. (4)
Check all parts are aligned
correctly and are secure. (5)
1
2
3
4
5
