Reolink Argus 3 Operational Instruction

• PIR Sensor Detecting Range
• Find the Best Spot for the
Camera
The PIR detection range can be customized to meet your specific needs. You can refer to the
following table to set it up in the Reolink App.
NOTICE: The path to adjust the Sensitivity on Reolink App: Device Settings-> PIR Settings->
Sensitivity.
Please install the camera 2-3 meters (7-10 ft)
above the ground. The detection range of
the motion sensor would be maximized at
such a height.
For eective motion detection, please install
the camera angularly and the angle
between the PIR sensor and the detected
object must be larger than 10°.
NOTICE: Due to the limitation of PIR sensor
detection, if a moving object approaches
the PIR sensor vertically (the direction of the
orange arrow in the image), the camera
may fail to detect motion.
Notes on Camera Installation
6English
5 English
B
θ
Mounting Height:
2-3 Meters
PIR Detecting Distance:
2-10 Meters
A
Sensitivity
High
Mid
Low
Up to 10 meters (33ft)
Up to 6 meters (20ft)
Up to 4 meters (13ft)
Value
81 - 100
51 - 80
0 - 50
Detecting Distance
(
For moving and living objects )

Reolink Argus 3 Specifications

General

Field of View	120°
Audio	Two-Way Audio
Weatherproof	IP65
Wireless Standard	IEEE 802.11b/g/n
Operating Temperature	-10°C to 55°C (14°F to 131°F)
Dimensions	121 x 90 x 56 mm
Resolution	2K (4MP)
Power Source	Rechargeable battery or solar panel
Connectivity	Wi-Fi (2.4GHz)
Image Sensor	CMOS Sensor
Video Resolution	2560 x 1440
Infrared Night Vision	Up to 10 meters (33ft) (IR LED)
Color Night Vision	Yes
PIR Detection Distance	Up to 10 meters
PIR Detection Angle	100°
Wireless Security	WPA-PSK/WPA2-PSK
Battery	5200mAh Rechargeable Battery
Power	Solar panel compatible
Local Storage	microSD card (up to 128GB)
Storage	Micro SD card
Motion Detection	PIR motion detection
Weight	330g
Lens	Fixed Lens, f=2.8mm
