Reolink Argus 3 Operational Instruction

• Install the Camera with Loop Strap
• with Security Mount
12English11 English
Step 1
Rotate to separate parts of
the bracket.
Step 2
Drill holes in accordance with the mounting hole template
and screw the security mount to the wall.
Screw the base of the camera bracket onto the wall and then
attach the other part of the bracket onto the base.
Step 4
Attach the camera on the wall mount and twist the camera
in any direction you want.
Step 4
Adjust the camera angle to get
the best field of view when you
watch live feed via Reolink App.
NOTICE: If you want to adjust the camera angle later, please loosen the bracket by turning the
upper part anti-clockwise.
Step 3
Screw the camera to the
bracket.
Step 5
Secure the camera by turning
the part on the bracket
identified in the chart clockwise.
Thread the loop strap
through the slots and
fasten the strap. It is the
best way to attach the
camera to a tree.

Reolink Argus 3 Specifications

General

Field of View	120°
Audio	Two-Way Audio
Weatherproof	IP65
Wireless Standard	IEEE 802.11b/g/n
Operating Temperature	-10°C to 55°C (14°F to 131°F)
Dimensions	121 x 90 x 56 mm
Resolution	2K (4MP)
Power Source	Rechargeable battery or solar panel
Connectivity	Wi-Fi (2.4GHz)
Image Sensor	CMOS Sensor
Video Resolution	2560 x 1440
Infrared Night Vision	Up to 10 meters (33ft) (IR LED)
Color Night Vision	Yes
PIR Detection Distance	Up to 10 meters
PIR Detection Angle	100°
Wireless Security	WPA-PSK/WPA2-PSK
Battery	5200mAh Rechargeable Battery
Power	Solar panel compatible
Local Storage	microSD card (up to 128GB)
Storage	Micro SD card
Motion Detection	PIR motion detection
Weight	330g
Lens	Fixed Lens, f=2.8mm
