Reolink Argus Eco User Manual

Reolink Wireless Battery-powered Camera
94
Battery Information
User can check the battery status and level here.
1. Launch the Reolink App and tap > Battery.
The camera battery level will be displayed as picture below.
low battery level below 15%
full battery
15%-30%
connected with charger, not charging
connect with DC charger and charging
connected with solar panel, not
charging
connected with solar panel and
charging

Reolink Argus Eco Specifications

Video

video resolution	1080p HD at 15 frames/sec
field of view	100° diagonal
night vision range	10 m (33 ft)

PIR Detection & Alerts

PIR detection distance	up to 10 m (33 ft)
PIR detection angle	100° horizontal
audio alert	customized voice-recordable alerts

General

operating temperature range	-10°C to 55°C (14°F to 131°F)
weather resistance	IP65 certified weatherproof
size	71 x 186 mm

Weight and Dimensions

weight	320 g (11.2 oz)
operating frequency	2412MHz—2472MHz
maximum transmitted power	18 dBm
