Reolink E1 Quick Start Guide

Mount the Camera
Step 1
Drill two holes on the
wall according to the
mounting hole
template.
Step 2
Insert the two plastic
anchors into the holes.
Step 3
Secure the base unit in
place by tightening the
screws into the plastic
anchors.
Step 4
Align the camera with
the bracket and turn the
camera unit clockwise
to lock it in position.
NOTE:
1. To remove it from the
wall, turn the camera
anticlockwise.
2. In case your camera is
mounted upside down, its
picture shall be rotated
as well. Please go to
Device Settings ->
Display on Reolink
app/Client and click
Rotation to adjust the
image.
6English
5 English

Reolink E1 Specifications

General

Pan & Tilt	355° Pan, 50° Tilt
Audio	Two-way audio
Storage	microSD card slot (up to 128GB)
Image Sensor	1/2.7" CMOS Sensor
Wireless Standard	IEEE 802.11b/g/n
Wireless Security	WPA-PSK/WPA2-PSK
Ethernet	No
Operating Temperature	-10°C to 55°C (14°F to 131°F)
Weight	200g
Motion Detection	Yes
Resolution	2304x1296 (3MP)
Night Vision	40 ft (12m)
Connectivity	Wi-Fi
Power	DC 5V/1A
IR Distance	40 ft (12m)
Day/Night Mode	Auto-switching
Viewing Angle	Horizontal: 87.5°, Vertical: 47°, Diagonal: 100°
