Reolink RLC-811A User Manual

4English
3 English
Camera Introduction
Infrared Lights
Lens
Daylight Sensor
Built-in Mic
Waterproof Lid
Network Cable
Reset Button
* Press for about 10 seconds to restore the
device to factory settings.
Power Port(Optional)
Waterproof Lid
Network Cable
Reset Button
* Press for about 10 seconds to restore the
device to factory settings.
Power Port(Optional)
Lens
Metal Case
Daylight Sensor
Infrared Lights
Mount
Mount
Built-in Mic

Reolink RLC-811A Specifications

General

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Infrared (IR) cut-off filter	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Protection features	Waterproof
International Protection (IP) code	IP66
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	12 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Number of users	20 user(s)
User access level	Administrator, User
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Ethernet LAN (RJ-45) ports	1
Mobile operating systems supported	Android, iOS
Audio system	2-way
Total megapixels	8 MP
Maximum resolution	3840 x 2160 pixels
Video compression formats	H.265
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	4
Sensor type	CMOS
Optical sensor size	1/2.8 \
Optical zoom	5 x

Weight and Dimensions

Depth	72 mm
Width	80 mm
Length	238 mm
Weight	838 g
