Reolink RLC-811A User Manual

Stien the adjustment knob to
lock the camera.
Drill holes in accordance with the
mounting hole template.
NOTE: There are two dierent types of mounts for bullet cameras.
Please check out the mount included in the package and follow the
corresponding instruction to install the camera properly.
NOTE: Use the drywall anchors
included in the package if needed.
NOTE: Run the cable through the
cable notch on the mount base.
Install the mount base with the
mounting screws included in
the package.
To get the best field of view,
loosen the adjustment knob
on security mount and turn
the camera.
Install the Camera
10English9 English
1
2
3
4

Reolink RLC-811A Specifications

General

Type	IP security camera
Placement supported	Outdoor
Connectivity technology	Wired
Infrared (IR) cut-off filter	Yes
Built-in HDD	No
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	256 GB
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	White
Protection features	Waterproof
International Protection (IP) code	IP66
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	12 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Number of users	20 user(s)
User access level	Administrator, User
Networking standards	IEEE 802.3af
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Ethernet LAN (RJ-45) ports	1
Mobile operating systems supported	Android, iOS
Audio system	2-way
Total megapixels	8 MP
Maximum resolution	3840 x 2160 pixels
Video compression formats	H.265
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Number of illumination LEDs	4
Sensor type	CMOS
Optical sensor size	1/2.8 \
Optical zoom	5 x

Weight and Dimensions

Depth	72 mm
Width	80 mm
Length	238 mm
Weight	838 g
