18B
-REMOVE BOLT, U-CONNECTOR, AND CABLE BALL FROM UPPER CABLE.
-CABLE BALLS MAY VARY IN SIZE. KEEP ALL BALLS WITH ORIGINAL CABLES.
2X NOT INCLUDED
17MM
UPPER
CABLE
TIP: LIFT THE HEADPLATE AND INSERT THE WEIGHT
SELECTOR PIN IN THE SECOND PLATE, LEAVING
AT LEAST TWO PLATES WORTH OF GAP BETWEEN
THE HEADPLATE AND SECOND PLATE AS SHOWN.
DOING SO WILL MAKE CABLE INSTALLATION EASIER.
