Transmitter Receiver
Dimension 600*520*35mm Dimension 105*57*11mm
Material PC Material ABS
Transmit power 480mW Receiving sensitivity -114dB
Maximum power 18W Li-polymer 3.7V/200mAh
433MHz
433MHz
Power supply DC12V/2A Receiving distance ＞900M open
area
Launch distance ＞900M open
Standby time ≈3 hour
Support receiver 99(18/set) Power mode Vibration/Beep/
Flashing
IP grade IP33 IP grade IP33
3
Diagram of receiver
Pairing method
Adjust reminding time for receiver
Problems Reasons Solutions
While power on, the
number display on
The power adaptor is
broken.
Change the power
adaptor.
The distance of some
receiver gets near.
The battery is low. Change the battery in
time.
Receiver can't get any
signal from keypad.
The number is not
correct.
Pair the receiver again
to the keypad.
Forget the number of
receiver.
Delete the pairing first,
then pair it again.
Transmitter Keypad 1 pcs
Charger 1 pcs
User Manual 1 pcs
