Page 23 of 89

©Retrotec 2017

5.4.6. Power Cord

The power cord is used to power your Model 300 fan. Once it is connected to a

wall outlet, the Mains Power status light turns green, indicating power is

connected.

5.4.7. 9v Power Supply adapter for charging DM32 gauge

A battery charger is included to charge the DM32 gauge’s batteries. For

instructions on charging the DM32 batteries refer to the DM32 Manual.

5.4.8. Additional parts and accessories for the DucTester

For options and accessories look at: retrotec.com

For more information on these parts, contact sales@retrotec.com
